EGG.1B.306.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 6POS SOLDER CUP
PDF
/
Buying Options
Total Price: USD $32.87
Unit Price: USD $32.868
≥1 USD $32.868
≥10 USD $28.78304
≥100 USD $27.539072
≥500 USD $26.650624
≥1000 USD $25.762352
≥3000 USD $24.340941
Inventory: 570
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 23mm
Diameter 15.8mm
Technical
Contact Resistance 5.6mOhm
Contact Style Socket
Contact Gender Female
Voltage - Rated AC 460V
Shell Size - Insert 306
Shell Finish Chrome
Current Rating 7A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Receptacle
Color Silver
Number of Positions 6
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 1B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Material Brass
Mounting Feature Bulkhead - Rear Side Nut
Mounting Type Panel Mount
Mount Flanges, Panel, Rear Side Nut
Contact Material Bronze
Supply Chain
Factory Lead Time 12 Weeks
