ECG.2B.310.CLV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors FIXED RECEPTACLE
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 10
Orientation G
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 6A
Shell Finish Chrome
Shell Size - Insert 310
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics CORROSION/MOISTURE RESISTANT
Coupling Type SNAP
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 10
Connector Type Receptacle, Female Sockets
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C
Dimensions
Diameter 19.2mm
Length 21.8mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Material Bronze
Supply Chain
Factory Lead Time 12 Weeks
