ECG.1B.306.CLV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 6P FEMALE R/A PCB R/A PANEL MOUNT
PDF
/
Buying Options
Total Price: USD $41.45
Unit Price: USD $41.448
≥1 USD $41.448
≥10 USD $38.03272
≥100 USD $36.569632
≥500 USD $35.350656
≥1000 USD $33.400312
≥3000 USD $32.425114
Inventory: 70
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 19.8mm
Diameter 15.8mm
Technical
Contact Resistance 5.6mOhm
Contact Gender Female
Voltage - Rated AC 460V
Shell Size - Insert 306
Shell Finish Chrome
Current Rating 7A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Current Rating (Amps) 6A
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Receptacle
Color Silver
Number of Positions 6
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 1B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Material Bronze
Supply Chain
Factory Lead Time 12 Weeks
