ECG.1B.304.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors INSERT FOR SIZE 1B RECEPT 4 POS
PDF
/
Buying Options
Total Price: USD $30.44
Unit Price: USD $30.4392
≥1 USD $30.4392
≥10 USD $26.65168
≥100 USD $25.500288
≥500 USD $24.677488
≥1000 USD $23.854952
≥3000 USD $22.538806
Inventory: 233
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 19.8mm
Diameter 15.8mm
Technical
Wire/Cable Gauge 22 AWG
Contact Style Socket
Contact Gender Female
Voltage - Rated AC 1.35kV
Shell Size - Insert 304
Shell Finish Chrome
Current Rating 10A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Voltage - Rated DC 1.91kV
Fastening Type Push-Pull
Color Silver
Number of Positions 4
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 1B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount
Mount Front, Panel, Rear Side Nut
Contact Material Bronze
Supply Chain
Factory Lead Time 12 Weeks
