KPSE6E18-11PDN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-DTL-26482 Circular Connector
PDF
/
Inventory: 7635
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series KPSE
Feature Shrink Boot Adapter
Part Status Active
Termination Crimp
Connector Type Plug, Male Pins
Number of Positions 11
Color Olive Drab
Gender Male
Voltage - Rated 1000VAC 1400VDC
Additional Feature STANDARD: MIL-DTL-26482
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 11
Orientation N (Normal)
Ingress Protection Environment Resistant
Current Rating 13A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 18-11
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
