KPSE01F24-61SX
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-26482POLARIZED COMPATIBLE CONTACTS: 031-8704-203 Circular Connector
PDF
/
Inventory: 6990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 51.1mm
Technical
Coupling Type BAYONET
Plating Cadmium, Chromate
Max Current Rating 7.5A
Shell Size 24
Environmental Characteristics MOISTURE RESISTANT
Body/Shell Style PLUG
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 61
Shell Finish CHROMATE PLATED
Depth 46mm
Orientation Straight
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Additional Feature STANDARD: MIL-C-26482, POLARIZED, COMPATIBLE CONTACTS: 031-8704-203
Gender Female
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type MIL SERIES CONNECTOR
Termination Crimp
Part Status Active
Pbfree Code no
JESD-609 Code e4
Packaging Bulk
Physical
Shell Material ALUMINUM ALLOY
Mount Cable
Contact Plating Gold
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
