CA3106F32A10SBF80A176
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3106F32A10SBF80A176Circular Connector, CA-B Series, MIL-DTL-5015 Series Equivalent, Straight Plug, 54 Contacts
PDF
/
Buying Options
Total Price: USD $244.4
Unit Price: USD $244.396979
≥1 USD $244.396979
≥10 USD $230.563185
≥100 USD $217.512445
≥500 USD $205.200419
≥1000 USD $193.5853
Inventory: 7695
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 19.7μin 0.50μm
Technical
Body Plating Cadmium
Environmental Characteristics CORROSION RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 32-A10
Shell Finish Olive Drab Cadmium
Current Rating 22A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation N (Normal)
Total Number of Contacts 54
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Reverse Bayonet Lock
Voltage - Rated 50V
Gender Female
Color Olive Drab
Number of Positions 54
Connector Type Plug, Female Sockets
Termination Crimp
Part Status Active
Series MIL-DTL-5015, CA-B
Published 2013
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Aluminium
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
