1318614-1

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description High Speed / Modular Connectors 040-3HD 86P CAP ASY
PDF
/
Inventory: 3769
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Plating Tin
Mount Through Hole
Housing Material Polybutylene

Technical

Packaging Bulk
Published 2005
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type Tab
Number of Positions 86
Max Operating Temperature 221°C
Min Operating Temperature -22°C
Color Natural
Number of Rows 3
Gender Female
Pitch 2.5mm
Orientation Right Angle
Shielding Unshielded
Contact Length - Mating 7.112mm
ELV Compliant
Max Voltage Rating (DC) 12V
Circuit Application Signal

Dimensions

Length 33.8582mm
Width 137.3886mm
PCB Thickness 1.6mm
Tab Thickness 640μm
Width - Tab 1mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 HB
