CA3106E24-9PDN
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
STANDARD: MIL-C-5015 Circular Connector
PDF
/
Inventory: 5571
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status Non-RoHS Compliant
Technical
Environmental Characteristics CORROSION RESISTANT
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 24-9
Shell Finish Olive Drab Cadmium
Current Rating 135A
Ingress Protection IP65 - Dust Tight, Water Resistant
Orientation N (Normal)
Total Number of Contacts 2
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Additional Feature STANDARD: MIL-C-5015
Voltage - Rated 50V
Gender Male
Color Olive Drab
Number of Positions 2
Connector Type Plug, Male Pins
Termination Solder Cup
Part Status Active
Feature Shrink Boot Adapter
Series MIL-DTL-5015, CA
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
