MS27467E25B46SLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors - Housings
Description
STANDARD: MIL-DTL-38999COMPATIBLE CONTACTS: M39029/56-352; M39029/56-351; M39029/56-366 Housing Circular Connector
PDF
/
Inventory: 4371
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Contact Finish Termination GOLD
Contact Size 16 4 20 40 8 Coax 2
Note Contacts Not Included
Empty Shell YES
Housing Color Olive Drab
Shell Size - Insert 25-46
Shell Finish Cadmium over Nickel
Ingress Protection Environment Resistant
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 46
Option GENERAL PURPOSE
Contact Type Crimp
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating GOLD
Fastening Type Bayonet Lock
HTS Code 8536.69.40.20
Additional Feature STANDARD: MIL-DTL-38999, COMPATIBLE CONTACTS: M39029/56-352; M39029/56-351; M39029/56-366
Number of Positions 46 (44 + 2 Coax)
Type For Female Sockets
Connector Type Plug Housing
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Coupling Nut
Series Military, MIL-DTL-38999 Series I, LJT
Published 2014
Packaging Bulk
Operating Temperature -65°C~175°C
Physical
Shell Material Aluminum Alloy
Contact Shape Circular
Mounting Type Free Hanging (In-Line)
Supply Chain
Factory Lead Time 16 Weeks
