RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description AMPHENOL PT00A12-4PWCircular Connector, PT Series, MIL-DTL-26482 Series I Equivalent, Wall Mount Receptacle, 4 Contacts
PDF
/
Inventory: 1462
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Insert Material Neoprene
Body Material Aluminium
Backshell Material, Plating Aluminum, Olive Drab Cadmium

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2006
Series MIL-DTL-26482 Series I, PT
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
ECCN Code EAR99
Connector Type Receptacle, Male Pins
Number of Positions 4
Color Olive Drab
Applications Aerospace, Industrial, Instrumentation, Mass Transit, Military
Gender Receptacle
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
Orientation W
Shielding Unshielded
Current Rating 13A
Shell Finish Olive Drab Chromate over Cadmium
Shell Size - Insert 12-4
Contact Style Pin
Body Plating Cadmium

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
