PC00P-8-2S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Miniature Cylindrical SKT 2 POS Solder ST Wall Mount 2 Terminal 1 Port
PDF
/
Inventory: 5866
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Insert Material Neoprene
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2005
Series MIL-DTL-26482 Series I, PC
Feature Potted
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 2
Gender Female
Additional Feature POLARIZED
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 2
Orientation N (Normal)
Shielding Unshielded
Current Rating 7.5A
Shell Finish Clear Chromate over Bright Cadmium
Shell Size - Insert 8-2
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
