RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN RCPT FMALE 9POS SOLDER CUP
PDF
/
Inventory: 1820
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

Environmental Characteristics CORROSION RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 28-4
Shell Finish Olive Drab Chromate over Cadmium
Reach Compliance Code unknown
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 9
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Additional Feature STANDARDS: MIL-DTL-5015; MIL-5015
Gender Female
Applications Marine, Military
Color Olive Drab
Number of Positions 9
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
JESD-609 Code e4
Series MIL-5015 Type
Published 2005
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Backshell Material, Plating Aluminum Alloy, Olive Drab Chromate over Cadmium
Insert Material Neoprene
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
