MS17343R32N17P image
Favorite
MS17343R32N17P image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Conn MIL-C-22992 Circular PIN 4 POS Crimp ST Wall Mount 4 Terminal 1 Port
PDF
/
Inventory: 4165
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Technical

Environmental Characteristics CORROSION RESISTANT
Backshell Type SOLID
Empty Shell NO
Shell Size - Insert 32-17
Shell Finish Anodic Coating (Alumilite)
Ingress Protection Waterproof
Shielding Unshielded
Orientation N (Normal)
Total Number of Contacts 4
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Silver
Fastening Type Threaded
Applications Military
Number of Positions 4
Connector Type Receptacle, Male Pins
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Series Military, MIL-DTL-22992
Published 2003
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
