TVPS00RF-25-11PC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Conn MIL-DTL-38999 Circular PIN 11 POS Crimp ST Wall Mount 11 Terminal 1 Port
PDF
/
Inventory: 4091
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Insert Material Thermoplastic
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series MIL-DTL-38999 Series III, Tri-Start? TV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Male Pins
Number of Positions 11 (2 + 9 Power)
Color Silver
Applications Aviation, Marine, Military
Gender Female
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts YES
Option GENERAL PURPOSE
Orientation C
Shielding Shielded
Ingress Protection Environment Resistant
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 25-11
Number of Contacts 11
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
Empty Shell YES
Backshell Type SOLID
Plating Electroless Nickel
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Environment Resistant
