TVP00RL-19-18PB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 3201
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Shell Size - Insert 19-18
Shell Finish Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation B
Contact Finish - Mating Gold
Fastening Type Threaded
Applications Aviation, Marine, Military
Color Silver
Min Operating Temperature -65°C
Max Operating Temperature 200°C
Number of Positions 18 (14 + 4 Twinax)
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2012
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Stainless Steel
Number of Pins 18
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Plating Gold
Contact Material Copper Alloy
