MS3471L22-55P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 55P SZ 22 WALL MOUNT PIN RECEPT W/ FLANGE
PDF
/
Buying Options
Total Price: USD $76.27
Unit Price: USD $76.2696
≥1 USD $76.2696
≥10 USD $66.0968
≥100 USD $58.3264
≥500 USD $52.184
≥1000 USD $45.76
Inventory: 142
Minimum: 1
-
+
Technical Details
Technical
Current Rating 7.5A
Military Standard MIL-DTL-26482
Shell Finish Electroless Nickel
Shell Size - Insert 22-55
Number of Contacts 55
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics FLUID RESISTANT
Plating Electroless Nickel
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation N (Normal)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Additional Feature STANDARD: MIL-C-26482, COMPATIBLE CONTACT: M39029/4-110
Applications Aviation, Industrial, Military
Color Silver
Number of Positions 55 (Power)
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-26482 Series II
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant, IP67
Physical
Shell Material Aluminum
Number of Pins 20
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
