RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Inventory: 2813
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Fluid Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Environmental Characteristics ENVIRONMENT/FLUID/IMMERSION RESISTANT
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 7
Shell Size - Insert 24-10
Shell Finish Electroless Nickel
Ingress Protection Fluid Resistant
Shielding Unshielded
Orientation Z
Current Rating (Amps) 46A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Gender Female
Applications Automotive, Military
Color Silver
Number of Positions 7 (Power)
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Military, MIL-DTL-5015
Published 2001
Packaging Bulk
Operating Temperature -55°C~200°C

Physical

Shell Material Aluminum
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel, Wall
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
