MS27656T9B98S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 3P FM SZ 9 SOCKET
PDF
/
Buying Options
Total Price: USD $19.85
Unit Price: USD $19.8528
≥1 USD $19.8528
≥10 USD $19.24208
≥100 USD $18.667968
≥500 USD $18.126944
≥1000 USD $17.61628
≥3000 USD $17.1336
Inventory: 18
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series I, LJT
JESD-609 Code e4
Feature Shielded
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 3
Color Olive Drab
Applications Aviation, Military
Gender Receptacle
Voltage - Rated 850V
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 3
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 23.82mm
Current Rating 7.5A
Military Standard MIL-DTL-38999
Shell Finish Olive Drab Cadmium over Nickel
Shell Size - Insert 9-98
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Plating Cadmium
Wire/Cable Gauge 20 AWG
Dimensions
Length 32.33mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
