MS27497T14F15P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Subminiature Cylindrical PIN 15 POS Crimp ST Wall Mount 15 Terminal 1 Port
PDF
/
Inventory: 1811
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel, Wall
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2000
Series Military, MIL-DTL-38999 Series II, JT
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Male Pins
Number of Positions 15
Color Silver
Applications Aviation, Military
Gender Receptacle
HTS Code 8536.69.40.20
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 15
Orientation N (Normal)
Shielding Unshielded
Ingress Protection Environment Resistant
Depth 28.57mm
Current Rating 13A
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 14-15
Contact Gender Male
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Plating Electroless Nickel, Passivated, Steel
Body Plating Electroless Nickel
Dimensions
Length 22.47mm
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Ratings Environment Resistant
