MS27484E12B4S
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Circular MIL Spec Connector 4P SZ 12 PLUG CBL MNT SKT
PDF
/
Buying Options
Total Price: USD $128.09
Unit Price: USD $128.089166
≥1 USD $128.089166
≥10 USD $120.838833
≥100 USD $113.9989
≥500 USD $107.54613
≥1000 USD $101.45862
Inventory: 7075
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Cable
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium
Technical
Operating Temperature -65°C~175°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
Feature Coupling Nut, Ground
Pbfree Code no
Part Status Active
Termination Crimp
Connector Type Plug, Female Sockets
Number of Positions 4
Color Olive Drab
Applications Aviation, Marine, Military
Gender Male
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 4
Orientation N (Normal)
Shielding Shielded
Ingress Protection Environment Resistant
Military Standard MIL-DTL-38999
Shell Finish Olive Drab Cadmium over Nickel
Shell Size - Insert 12-4
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Plating Cadmium
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
