MS27472P14F35P
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 37POS GOLD CRIMP
PDF
/
Inventory: 9900
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper Alloy
Mount Flanges, Panel
Mounting Type Panel Mount
Mounting Feature Flange
Shell Material Aluminum
Body Material Aluminium
Technical
Operating Temperature -65°C~200°C
Packaging Bulk
Published 2006
Series Military, MIL-DTL-38999 Series II, JT
Feature Potted
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 37
Color Silver
Applications Aviation, Military
Gender Receptacle
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 37
Orientation N (Normal)
Shielding Unshielded
Current Rating 5A
Military Standard MIL-DTL-38999
Shell Finish Electroless Nickel
Shell Size - Insert 14-35
Contact Gender Male
Empty Shell NO
Backshell Type SOLID
Contact Style Pin
Plating Passivated, Steel
Cable Opening 0.808 (20.52mm)
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
