MS27468E25B35SD image
Favorite
MS27468E25B35SD image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description CONN RCPT 128POS JAM NUT W/SCKT
PDF
/
Inventory: 1623
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Environment Resistant
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness - Mating 50.0μin 1.27μm

Technical

Plating Cadmium
Contact Style Socket
Empty Shell NO
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 25-35
Shell Finish Olive Drab Cadmium over Nickel
Military Standard MIL-DTL-38999
Current Rating 5A
Ingress Protection Environment Resistant
Shielding Unshielded
Orientation D
Total Number of Contacts 128
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Bayonet Lock
Applications Aviation, Military
Color Olive Drab
Number of Positions 128
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Shielded
JESD-609 Code e4
Series Military, MIL-DTL-38999 Series I, LJT
Published 2006
Packaging Bulk
Operating Temperature -65°C~175°C

Physical

Shell Material Aluminum
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Jam Nut, Panel
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 16 Weeks
