CTVS07RF-25-35PA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
AMPHENOL CTVS07RF-25-35PA Circular Connector, Tri-Start CTV Series, MIL-DTL-38999 Series III Equivalent, Jam Nut Receptacle
PDF
/
Buying Options
Total Price: USD $1023.88
Unit Price: USD $1023.88
≥1 USD $1023.88
≥10 USD $895.8928
≥100 USD $796.4
≥500 USD $568.8496
Inventory: 114
Minimum: 1
-
+
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness - Mating 50.0μin 1.27μm
Technical
Body Plating Electroless Nickel
Backshell Type SOLID
Empty Shell YES
Shell Size - Insert 25-35
Shell Finish Electroless Nickel
Reach Compliance Code unknown
Ingress Protection Environment Resistant
Shielding Shielded
Orientation A
Total Number of Contacts 128
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating Gold
Fastening Type Threaded
HTS Code 8536.69.40.20
Gender Receptacle
Applications Aviation, Marine, Military
Color Silver
Number of Positions 128
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MIL-DTL-38999 Series III, Tri-Start? TV
Published 2006
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Composite
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front Side Nut, Panel
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 16 Weeks
