CTVPS00RF-25-24HE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT MALE 24POS GOLD CRIMP
PDF
/
Inventory: 8155
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Environment Resistant
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 100.0μin 2.54μm
Technical
Shell Size - Insert 25-24
Shell Finish Electroless Nickel
Ingress Protection Environment Resistant
Shielding Shielded
Orientation E
Contact Finish - Mating Gold
Fastening Type Threaded
Applications Aviation, Marine, Military
Color Silver
Min Operating Temperature -65°C
Max Operating Temperature 200°C
Number of Positions 24
Connector Type Receptacle, Male Pins
Termination Crimp
Part Status Active
Feature Shielded
Series MIL-DTL-38999 Series III, Tri-Start? TV
Packaging Bulk
Operating Temperature -65°C~200°C
Physical
Insert Material Thermoplastic
Shell Material Composite
Number of Pins 24
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Plating Gold
Contact Material Copper Alloy
