534975-7
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 24 MODII 2PC DR CE R
PDF
/
Inventory: 6577
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
PCB Thickness 1.57mm
Length - Termination 0.115 inch
Contact Finish Thickness - Mating 381 nm
Technical
High Temperature Compatible Yes
Mating Alignment With
Contact Rating (Current) 3A
Mating Post Length 3.17mm
Circuit Application Signal
Contact Pattern RECTANGULAR
Durability 75 Cycles
PCB Contact Row Spacing 7.874 mm
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLAR PIN POSITION
Plating Gold
ELV Non-Compliant
Insulation Resistance 5GOhm
Contact Style BELLOWED TYPE
Rated Current (Signal) 2A
Operating Supply Voltage 250V
Lead Length 2.92mm
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number of Contacts 24
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Body Length or Diameter 1.458 inch
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 250V
Number of Conductors ONE
Current Rating 3A
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature AMPMODU
Number of Rows 2
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination Solder
Pbfree Code no
Packaging Bulk
Physical
PCB Mount Alignment Without
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
