6282
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors - Accessories
Description
CONN COUPLING RING BLACK
PDF
/
Buying Options
Total Price: USD $0.65
Unit Price: USD $0.648843
≥1 USD $0.648843
≥10 USD $0.612116
≥100 USD $0.577467
≥500 USD $0.544783
≥1000 USD $0.513942
Inventory: 2004
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type BOARD
Material Nylon
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Board Mounting Option PEG
Technical
Series Mini-Con-X?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type BOARD CONNECTOR
Color Black
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating AU ON NI
Total Number of Contacts 28
Terminal Pitch 1.27mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.122 inch
Contact Gender FEMALE
Operating Temperature (Min) -40°C
Body Depth 0.177 inch
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.05 inch
Termination Type SURFACE MOUNT
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 300VAC V
PCB Contact Row Spacing 3.556 mm
Durability 50 Cycles
Accessory Type Coupling Nut
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.05 inch
Dimensions
Plating Thickness 30μin
Compliance
RoHS Status ROHS3 Compliant
