CSS2725JTL500
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Resistors / Chip Resistor - Surface Mount
Description
CSS FIXED RESISTOR Nonstandard Chip Resistor ±5% ±50ppm/C 500muOhm 4W
PDF
/
Inventory: 8159
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Technical
Operating Temperature -55°C~225°C
Packaging Tape & Reel (TR)
Series CSS
Size / Dimension 0.268Lx0.254W 6.81mmx6.45mm
Tolerance ±5%
JESD-609 Code e3
Feature Automotive AEC-Q200, Current Sense
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Temperature Coefficient ±50ppm/°C
Resistance 500μOhm
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Composition Metal Element
Power (Watts) 4W
Packing Method TR, Plastic, 7 Inch
Construction Rectangular
Resistor Type FIXED RESISTOR
Rated Power Dissipation (P) 4W
Dimensions
Height Seated (Max) 0.049 1.24mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
