MCR18EZHF1003
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
1206 (3216Metric) FIXED RESISTOR MCR 0.126Lx0.063W 3.20mmx1.60mm 0.25W 1/4W 100kOhm ±100ppm/C
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.026 0.65mm
Height 660.4μm
Technical
Case Code (Imperial) 1206
Case Code (Metric) 3216
Resistor Type FIXED RESISTOR
Construction Rectangular
Max Power Dissipation 250mW
Packing Method TR, PAPER, 7 INCH
Voltage - Rated DC 200V
Power Rating 250mW
Subcategory Fixed Resistors
Power (Watts) 0.25W 1/4W
Composition Thick Film
Resistance 100kOhm
Temperature Coefficient ±100ppm/°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e3
Tolerance ±1%
Size / Dimension 0.126Lx0.063W 3.20mmx1.60mm
Series MCR
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -55°C~155°C
Physical
Terminal Shape WRAPAROUND
Package / Case 1206 (3216 Metric)
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 12 Weeks
