MCR01MRTJ000
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0402 (1005Metric) FIXED RESISTOR MCR 0.039Lx0.020W 1.00mmx0.50mm 0.063W 1/16W 0Ohm Jumper
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.02755
≥1 USD $0.02755
≥10 USD $0.0228
≥100 USD $0.02185
≥500 USD $0.0209
≥1000 USD $0.01995
Inventory: 1102
Minimum: 1
-
+
Technical Details
Physical
Package / Case 0402 (1005 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Mounting Feature SURFACE MOUNT
Technical
Operating Temperature -55°C~155°C
Packaging Tape & Reel (TR)
Published 2011
Series MCR
Size / Dimension 0.039Lx0.020W 1.00mmx0.50mm
Tolerance Jumper
JESD-609 Code e3
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Resistance 0Ohm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Composition Thick Film
Power (Watts) 0.063W 1/16W
Additional Feature RATED CURRENT: 1A
Subcategory FIXED RESISTOR
Power Rating 63mW
Voltage - Rated DC 50V
Packing Method TR, PAPER, 7 INCH
Max Power Dissipation 63mW
Construction Chip
Resistor Type FIXED RESISTOR
Reference Standard TS 16949
Case Code (Metric) 1005
Rated Power Dissipation (P) 0.063W
Case Code (Imperial) 0402
Dimensions
Height 406.4μm
Height Seated (Max) 0.016 0.40mm
Compliance
RoHS Status ROHS3 Compliant
