MCR006YZPJ135
RoHS
RoHS compliant
RoHS compliantPackage 0201 (0603 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0201 (0603Metric) FIXED RESISTOR MCR 0.024Lx0.012W 0.60mmx0.30mm 0.05W 1/20W 1.3MOhm ±250ppm/C
PDF
/
Inventory: 2683
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 0201 (0603 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Mounting Feature SURFACE MOUNT
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2012
Series MCR
Size / Dimension 0.024Lx0.012W 0.60mmx0.30mm
Tolerance ±5%
JESD-609 Code e3
Feature Automotive AEC-Q200
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient ±250ppm/°C
Resistance 1.3MOhm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Composition Thick Film
Power (Watts) 0.05W 1/20W
Additional Feature STANDARD: TS 16949
Subcategory FIXED RESISTOR
Power Rating 50mW
Voltage - Rated DC 25V
Packing Method TR, PAPER, 7 INCH
Max Power Dissipation 50mW
Construction Chip
Resistor Type FIXED RESISTOR
Case Code (Metric) 0603
Rated Power Dissipation (P) 0.05W
Case Code (Imperial) 0201
Dimensions
Height 254μm
Height Seated (Max) 0.010 0.26mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
