ERJ12SF2802U
RoHS
/
Package /
Category Resistors / Chip Resistor - Surface Mount
Description
FIXED RESISTOR Chip Resistor 1% 100ppm/C 28kOhm 750mW
PDF
/
Inventory: 1435
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 2.5mm
Length 5mm
Height 600μm
Technical
Rated Temperature 70°C
Case Code (Imperial) 2010
Rated Power Dissipation (P) 0.75W
Case Code (Metric) 5025
Reference Standard AEC-Q200
Resistor Type FIXED RESISTOR
Construction Chip
Packing Method TR, Embossed, 7 Inch
Power Rating 750mW
HTS Code 8533.21.00.30
Additional Feature PRECISION, STANDARD: IEC60115-8
Voltage - Rated 200V
Composition Thick Film
Min Operating Temperature -55°C
Max Operating Temperature 155°C
Resistance 28kOhm
Temperature Coefficient 100 ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Tolerance 1%
Physical
Terminal Shape WRAPAROUND
Mount Surface Mount
Contact Plating Tin
