WK73S2HTTER200F
RoHS
RoHS compliant
RoHS compliantPackage Wide 2010 (5025 Metric), 1020
Category Resistors / Chip Resistor - Surface Mount
Description
Wide 2010 (5025Metric) 1020 FIXED RESISTOR WK73S 0.098Lx0.197W 2.50mmx5.00mm 1W 200mOhm ±200ppm/C
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.2904
≥100 USD $0.208384
≥500 USD $0.182776
≥1000 USD $0.140078
≥3000 USD $0.126562
Inventory: 4487
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.028 0.70mm
Height 600μm
Technical
Case Code (Imperial) 1020
Rated Power Dissipation (P) 1W
Case Code (Metric) 2550
Resistor Type FIXED RESISTOR
Construction Rectangular
Packing Method TR, EMBOSSED PLASTIC, 7 INCH
Voltage - Rated DC 200V
Power Rating 1W
Voltage - Rated 200V
Composition Thick Film
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Resistance 200mOhm
Temperature Coefficient ±200ppm/°C
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Automotive AEC-Q200, Moisture Resistant
JESD-609 Code e3
Tolerance ±1%
Size / Dimension 0.098Lx0.197W 2.50mmx5.00mm
Series WK73S
Packaging Tape & Reel (TR)
Operating Temperature -55°C~155°C
Physical
Mounting Feature SURFACE MOUNT
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case Wide 2010 (5025 Metric), 1020
Supply Chain
Factory Lead Time 8 Weeks
