SG73S2ETTD393G
RoHS
RoHS compliant
RoHS compliantPackage 1210 (3225 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
1210 (3225Metric) FIXED RESISTOR SG73S 0.126Lx0.102W 3.20mmx2.60mm 0.5W 1/2W 39kOhm ±200ppm/C
PDF
/
Inventory: 4892
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.028 0.70mm
Height 600μm
Technical
Case Code (Imperial) 1210
Rated Power Dissipation (P) 0.5W
Case Code (Metric) 3225
Resistor Type FIXED RESISTOR
Construction Rectangular
Packing Method TR, PUNCHED PAPER, 7 INCH
Voltage - Rated DC 200V
Power Rating 500mW
Voltage - Rated 200V
Power (Watts) 0.5W 1/2W
Composition Thick Film
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Resistance 39kOhm
Temperature Coefficient ±200ppm/°C
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Automotive AEC-Q200, Moisture Resistant, Pulse Withstanding
JESD-609 Code e3
Tolerance ±2%
Size / Dimension 0.126Lx0.102W 3.20mmx2.60mm
Series SG73S
Packaging Tape & Reel (TR)
Operating Temperature -55°C~155°C
Physical
Mounting Feature SURFACE MOUNT
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 1210 (3225 Metric)
Supply Chain
Factory Lead Time 7 Weeks
