AHA80AJB-22R
RoHS
RoHS compliant
RoHS compliantPackage Axial, Box
Category Resistors / Chassis Mount Resistors
Description
AHA FIXED RESISTOR Axial Box Chassis Mount Resistor ±5% ±200ppm/C 22Ohm 2.598Lx1.850W 66.00mmx47.00mm
PDF
/
Inventory: 4734
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Package / Case Axial, Box
Mounting Feature Flanges
Housing Material Aluminium
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Published 2014
Series AHA
Size / Dimension 2.598Lx1.850W 66.00mmx47.00mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient ±200ppm/°C
Resistance 22Ohm
Composition Wirewound
HTS Code 8533.21.00.80
Subcategory Fixed Resistors
Max Power Dissipation 80W
Technology WIRE WOUND
Resistor Type FIXED RESISTOR
Lead Length 18mm
Working Voltage 2000V
Lead Style Threaded
Lead/Base Style Solder
Coating, Housing Type Aluminum
Dimensions
Height 26.0096mm
Height Seated (Max) 1.024 26.00mm
Compliance
RoHS Status ROHS3 Compliant
