F10J4K0E
RoHS
RoHS compliant
RoHS compliantPackage Radial, Flat Oval
Category Resistors / Chassis Mount Resistors
Description
Stackohm? 250 FIXED RESISTOR Radial Flat Oval Chassis Mount Resistor ±5% ±260ppm/C 4kOhm 10W
PDF
/
Buying Options
Total Price: USD $7.25
Unit Price: USD $7.245895
≥1 USD $7.245895
≥200 USD $2.804354
≥500 USD $2.705887
≥1000 USD $2.65731
Inventory: 8983
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Package / Case Radial, Flat Oval
Surface Mount NO
Terminal Shape LUG
Mounting Feature Flange Braces, Right Angle
Housing Material Vitreous Enamel Coated
Technical
Operating Temperature -55°C~350°C
Packaging Bulk
Published 2008
Series Stackohm? 250
Size / Dimension 0.750Lx0.375W 19.05mmx9.53mm
Tolerance ±5%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient ±260ppm/°C
Resistance 4kOhm
Terminal Finish Tin (Sn)
Composition Wirewound
Voltage - Rated 187V
HTS Code 8533.21.00.80
Subcategory Fixed Resistors
Power Rating 10W
Max Power Dissipation 10W
Technology WIRE WOUND
Resistor Type FIXED RESISTOR
Lead Style Solder Lugs
Lead/Base Style Solder
Coating, Housing Type Vitreous Enamel Coated
Dimensions
Diameter 9.525mm
Height 9.525mm
Height Seated (Max) 0.375 9.53mm
Compliance
RoHS Status ROHS3 Compliant
