SR501E105MAA

AVX Corporation
RoHS
/
Package Radial
Category Capacitors / Ceramic Capacitors
Description SR50(100VE) CERAMIC CAPACITOR Radial ceramic capacitor -56/+22% ppm/C 20% 1muF 50V
PDF
/
Inventory: 9281
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Capacitance 1μF
Voltage - Rated DC 50V
Lead Pitch 10.16mm
Capacitor Type CERAMIC CAPACITOR
Dielectric Z5U
Temperature Characteristics Code Z5U
Multilayer Yes
Rated (DC) Voltage (URdc) 100V
Lead Diameter 635 μm
Size Code 5020
HTS Code 8532.24.00.60
Min Operating Temperature 10°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Temperature Coefficient -56/+22% ppm/°C
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Tolerance 20%
Series SR50(100V,E)
Published 2013
Packaging Bulk

Dimensions

Height 12.7mm
Width 12.7mm
Thickness 5.08mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant

Physical

Terminal Shape WIRE
Package / Case Radial
Mount Through Hole

Supply Chain

Factory Lead Time 111 Weeks
