GNM1M25C1H680KD01D
RoHS
/
Package 0504 (1410 Metric)
Category Capacitors / Capacitor Networks, Arrays
Description
GNM ARRAY/NETWORK CAPACITOR 0504 (1410Metric) Isolated Capacitor 0.054Lx0.039W 1.37mmx1.00mm C0G NP0 ±10% 68pF
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.111673
≥1 USD $0.111673
≥200 USD $0.044559
≥500 USD $0.043069
≥1000 USD $0.042334
Inventory: 6251
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0504 (1410 Metric)
Terminal Shape WRAPAROUND
Dielectric Material Ceramic
Technical
Packaging Tape & Reel (TR)
Series GNM
Size / Dimension 0.054Lx0.039W 1.37mmx1.00mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Termination SMD/SMT
ECCN Code EAR99
Temperature Coefficient C0G NP0
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Capacitance 68pF
Voltage - Rated DC 50V
Packing Method TR, PAPER, 7 INCH
Number of Functions 2
Terminal Pitch 640μm
Depth 1mm
Capacitor Type ARRAY/NETWORK CAPACITOR
Dielectric C0G
Number of Elements 1
Temperature Characteristics Code C0G
Circuit Type Isolated
Number of Capacitors 2
Dimensions
Height 200μm
Height Seated (Max) 0.028 0.70mm
Length 1.37mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
