XMT332B
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Barrel Audio Connector
PDF
/
Inventory: 7224
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.252 (6.40mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Body Color Silver
Internal Switch(s) Does Not Contain Switch
Number of Positions/Contacts 3 Conductors, 3 Contacts
Number of Poles 3
Number of Ports 1
Configuration 1X1 HORIZONTAL
Shielding Unshielded
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Gender Female
Connector Type Phone Jack
Termination Solder Eyelet(s)
Part Status Active
Series XMT-Jax?
Published 2012
Packaging Bulk
Physical
Body Material Copper Alloy
Mounting Type Panel Mount
Mount Through Hole
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 12 Weeks
