SN70C12A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Barrel Audio Connector
PDF
/
Inventory: 3342
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 15.87mm
Technical
Signal Lines Mono
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Body Color Black
Internal Switch(s) Single Switch
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 2 Conductors, 3 Contacts
Thread Size 3/8-32
Number of Poles 2
Number of Ports 1
Shielding Unshielded
Orientation Horizontal
Pitch 7.62mm
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated 500V
Gender Female
Connector Type Phone Jack
Termination Solder
Number of Terminations 4
Part Status Active
Feature Mounting Hardware, Thread Lock
Series SN70C
Published 2005
Packaging Bulk
Physical
Contact Material - Plating Nickel
Housing Material Thermoplastic
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Nickel, Silver, Tin
Contact Material Brass
Supply Chain
Factory Lead Time 12 Weeks
