IPD1-15-D-K-M
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
SAMTEC IPD1-15-D-K-M Connector Housing, Dual Row, Receptacle, 30 Ways, 2.54 mm, CC79 Series Socket Crimp Contacts
PDF
/
Buying Options
Total Price: USD $3.29
Unit Price: USD $3.2912
≥1 USD $3.2912
≥10 USD $2.684
≥100 USD $2.2792
≥500 USD $2.024
≥1000 USD $1.856809
≥3000 USD $1.804009
Inventory: 2992
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 39.5mm
Technical
Contact Termination Crimp
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 30 AWG
Max Current Rating 7.4A
Max Voltage Rating (AC) 600V
Note Contacts Not Included
Row Spacing 0.100 (2.54mm)
Empty Shell NO
Depth 12.83mm
Orientation Straight
Total Number of Contacts 30
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Latch Lock
Number of Rows 2
Color White
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 30
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Pick and Place, Polarizing Key
Series Mini Mate? IPD1
Published 2013
Packaging Tube
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
