190A
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN PLUG STEREO 6.35MM 3COND
PDF
/
Buying Options
Total Price: USD $13.01
Unit Price: USD $13.010839
≥1 USD $13.010839
≥200 USD $5.034972
≥500 USD $4.85773
≥1000 USD $4.771079
Inventory: 7119
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Diameter 6.35mm
Technical
Mating Length/Depth 1.210 30.70mm
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Body Color Silver
Internal Switch(s) Does Not Contain Switch
Includes 3 pcs - 1 Connector, 1 Handle, 1 Insulator Tube
Number of Positions/Contacts 3 Conductors, 3 Contacts
Cable Opening 0.250 (6.35mm)
Number of Poles 3
Number of Ports 1
Shielding Shielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Gender Male
Connector Type Phone Plug
Termination Solder Eyelet(s)
Number of Terminations 3
Part Status Active
Packaging Bulk
Physical
Contact Material - Plating Nickel
Package / Case Metal
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Brass
Supply Chain
Factory Lead Time 12 Weeks
Alternative Model
