BAL-2690D3U
RoHS
RoHS compliant
RoHS compliantPackage 4-WFBGA, FCBGA
Category RF/IF and RFID / Balun
Description
BALUN TRANSFORMER FLIPCHIP
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.4928
≥1 USD $0.4928
≥10 USD $0.47872
≥100 USD $0.320672
≥500 USD $0.285472
≥1000 USD $0.261536
≥3000 USD $0.234643
Inventory: 1348
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-WFBGA, FCBGA
Number of Pins 4
Technical
Packaging Cut Tape (CT)
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Frequency 2.441GHz
DC Resistance (DCR) 50Ohm
Impedance 50Ohm
Bandwidth 2.441 GHz
Frequency Range 2.402GHz~2.48GHz
Insertion Loss (dB) 0.8 dB
Transformer Type RF TRANSFORMER
Insertion Loss (Max) 1.1dB
Return Loss-Min 14dB
Impedance - Unbalanced/Balanced 50 / -Ohm
Phase Difference 10°
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
