CX2047LNL
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category RF/IF and RFID / Balun
Description
RF Transformer 1:2CT 5Term. SMD
PDF
/
Buying Options
Total Price: USD $2.8
Unit Price: USD $2.7984
≥1 USD $2.7984
≥10 USD $2.26864
≥100 USD $1.834272
≥500 USD $1.71842
≥1000 USD $1.6412
≥3000 USD $1.59295
Inventory: 775
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 3.81mm
Height 2.79mm
Technical
Impedance - Unbalanced/Balanced 50 / 50Ohm
Return Loss-Min -25dB
Insertion Loss (Max) 4.0dB
Turns Ratio - Primary:Secondary 1:2
Transformer Type RF TRANSFORMER
Frequency Range 500KHz~300MHz
Physical Dimension L3.81XB3.81XH2.79 (mm)
Frequency 1.5GHz
Reach Compliance Code unknown
Depth 3.81mm
Additional Feature IMPEDANCE RATIO IS 1:4CT; HEIGHT DIM INCLUDES TERMINALS ALSO
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2010
Packaging Tray
Physical
Number of Pins 5
Package / Case 5-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
