3700BL15B100E
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category RF/IF and RFID / Balun
Description
BALUN CERAMIC CHIP WIMAX 3.7GHZ
PDF
/
Buying Options
Total Price: USD $11.13
Unit Price: USD $11.1302
≥1 USD $11.1302
≥10 USD $9.1333
≥100 USD $8.84735
≥500 USD $8.56235
≥1000 USD $8.2764
Inventory: 1238
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Phase Difference 180° ±20°
Impedance - Unbalanced/Balanced 50 / 100Ohm
Return Loss-Min 9.5dB
Insertion Loss (Max) 1.0dB
Insertion Loss (dB) 1 dB
Frequency Range 3.4GHz~4GHz
Impedance 100Ohm
Case Code (Imperial) 0805
Case Code (Metric) 2012
Frequency 3.7GHz
Composition Ceramic
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 3700
Published 2003
Packaging Tape & Reel (TR)
Physical
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
