6643223-1
RoHS
/
Package /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Power to the Board SLIMLINE ICCON PIN ASSY
PDF
/
Inventory: 6576
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length - Tail 5.18mm
Plating Thickness 5.08μm
Width 7.37mm
Length 25.32mm
Technical
Mating Post Length 11.94mm
ELV Compliant
Housing Color Black
Number of Contacts 1
Approval Agency UL
Current Rating 35A
Orientation Right Angle
Pitch 2.54mm
Voltage - Rated 250V
Color Black
Min Operating Temperature -40°C
Max Operating Temperature -105°C
Number of Positions 1
Connector Type Pin, Plug
Termination Press-Fit
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Silver
