1715747807
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Specialized Connector
PDF
/
Buying Options
Total Price: USD $159.71
Unit Price: USD $159.7102
≥1 USD $159.7102
≥10 USD $143.18875
Inventory: 161
Minimum: 1
-
+
Technical Details
Technical
Connector Style Impact, Guide Top
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Mating Contact Pitch 0.074 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Rated Current (Signal) 0.75A
Body Depth 1.673 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 12
Body Length or Diameter 0.992 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Number of Positions Loaded All
Total Number of Contacts 96
Subcategory Headers and Edge Type Connectors
Voltage - Rated 30V
Number of Rows 12
Color Black
Number of Positions 96
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
JESD-609 Code e3
Series Impact 171574
Published 2014
Packaging Tray
Operating Temperature -55°C~85°C
Number of Columns 8
Contact Layout, Typical 32 Differential Pairs
Withdrawl Force-Min .14734 N
Insertion Force-Max .3336 N
Contact Pattern RECTANGULAR
Durability 200 Cycles
PCB Contact Row Spacing 1.3462 mm
Physical
Mounting Option 2 LOCKING
Mounting Option 1 GUIDE PIN
Insulation Material GLASS FILLED LIQUID CRYSTAL POLYMER
Mounting Type Board Edge, Through Hole, Right Angle
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 13 Weeks
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.047 inch
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
