0765601127
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76560 ROHS3Compliant COMMERCIAL Gold Connector Header, Male Pins 200Cycles .3336N -55C~85C 0.75A
PDF
/
Inventory: 6230
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.047 inch
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Technical
Number of Columns 10
Contact Layout, Typical 60 Differential Pairs
Withdrawl Force-Min .14734 N
Insertion Force-Max .3336 N
Durability 200 Cycles
Connector Style Impact
Dielectric Withstanding Voltage 500VAC V
Rated Current (Signal) 0.75A
Reliability COMMERCIAL
Contact Finish Gold
Number of Conductors ONE
Number of Positions Loaded All
Total Number of Contacts 180
Pitch 0.053 1.35mm
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Voltage - Rated 30V
Number of Rows 18
Color Black
Number of Positions 180
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Impact 76560
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Mounting Option 1 LOCKING
Insulation Material THERMOPLASTIC
Mounting Type Board Edge, Through Hole, Right Angle
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 13 Weeks
