0761651135
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
High Speed / Modular Connectors Impact BP 3x10 RW Sn Impact BP 3x10 RW Sn
PDF
/
Inventory: 7278
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Plating Gold, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polymer
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76165
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Connector Type Header, Male Pins
Number of Positions 90
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Color Black
Number of Rows 9
Voltage - Rated 30V
Pitch 0.053 1.35mm
Orientation Vertical
Depth 16.7mm
Number of Positions Loaded All
Contact Finish Gold
Housing Color Black
Contact Resistance 10mOhm
Number of Circuits 90
Max Voltage Rating (AC) 30V
Connector Style Impact
Contact Layout, Typical 30 Differential Pairs
Number of Columns 10
Dimensions
Length 20.3mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
