0761550108
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76155 ROHS3Compliant GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE Connector Header, Male Pins -55C~85C 30V 30.0muin 0.76mum
PDF
/
Inventory: 4495
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Technical
Number of Columns 10
Contact Layout, Typical 40 Differential Pairs
Connector Style Impact
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Number of Positions Loaded All
Total Number of Contacts 120
Pitch 0.053 1.35mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.40
Voltage - Rated 30V
Number of Rows 12
Color Black
Number of Positions 120
Connector Type Header, Male Pins
ECCN Code EAR99
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series Impact 76155
Packaging Tray
Operating Temperature -55°C~85°C
Physical
Mounting Type Through Hole
Contact Material NOT SPECIFIED
